Hygrometer
A hygrometer is a device that helps to measure humidity. These are precision instruments
known by the name of humidity sensors or psychrometers. Such devices measure relative humidity
or the extent of vapor in the air to the maximum amount possible. The availability of a wide
variety of these devices makes it difficult for the customers to choose one.
Some hygrometers even measure temperature. Heatcon offers hygrometers that measure both
temperature and humidity. Two different displays reflect the metrics at the same time. These
devices are essential in diverse sectors such as agriculture, construction, heating,
ventilation, manufacturing, air conditioning, and many others. A hygrometer assesses the heat
stress risk in hot environments such as factories, commercial bakeries, boiler rooms, and
construction sites.
There are diverse types of hygrometers. Some are handheld and others need to be mounted
on a surface. The choice of hygrometer depends on the purpose for which it is to be deployed.
Heatcon manufactures quality hygrometers that can serve multiple processes across diverse
industries. These are cost-effective and come in a variety of specifications to suit different
customers’ needs.
DIGITAL HYGROMETER – HI-WP-9020E / 90X90 MM
Features
Heatcon Digital Hygrometer indicates the present temperature and humidity at the the same time On two different displays.Temperature is displayed on the upper LED display(RED) with ½inch and humidity on the lower LED display (Green) with ½ inch
Using capacitive sensor as Humidity sensor
Standard sizes available are:
Specifications of Digital Hygrometer
Temperature Sensor
Sensor: PT-100/PT-1000
Temperature Range : -20.0°C to 99.9°C
Accuracy : +/- 0.1°C
Resolution : 0.1°C
Response time : Less than 0.5 sec
Sheath Material : Stainless steel
Cable : Teflon/Teflon is used internally and externally silicon Insulated
Sensor stem : Dia 3 to 6mm
Sensor length : 50 to 150mm
Standard cable length :3 to 5 meters
Configuration : 2/3/4 wire
Sensor output : 4 to 20mA
Input power supply : 8-24V DC
Humidity sensor
Sensor : Capacitive
Accuracy : +/- 3% at 23°C
Humidity Range : 5% to 99%
Resolution : 1%
Response time : Less than 3 sec
Sensor Output : 4 to 20mA
Input power supply : 8-24V DC
HUMIDITY CONTROL – HI-9020-BD
Heatcon temperature –humidity controller not only indicates the present temperature and humidity but also controls both at the the same time.
Features
Temperature is displayed on the upper LED display(RED) with ½inch and humidity on the lower LED display (Green) with ½ inchSpecifications of Humidity Control
Input :RTD/4-20mATemperature range : -20.0 to 99.9 °C or as per custom requirement
Humidity Range : 5% to 99%
Resolution : 0.1°C or 0.1% Rh
